Small Cutting Size Fiber Laser Cutting Machine (ST-FC1390)

Small Cutting Size Fiber Laser Cutting Machine is a powerful cutting device. With its high speed, high precision and high reliability, it can effectively meet the diverse needs of modern manufacturing for small and fine cutting, and has become an ideal choice in the industry. It is widely used in electronics, accessories, sheet metal processing and other industries.
Product Model: ST-FC6060/ST-FC1390/ST-FC2010
Laser power: 1000W/1500W/2000W/3000W/4000W
Working area: 600*600/1300*900/2000*1000mm (customizable)

Availability:

Quantity:



Inquire PDF Export

Product Description

Details Product Parameters Samples Video

Product Introduction

With the continuous development of the manufacturing industry, advanced cutting technology is increasingly used in various industries. Among them, fiber laser cutting technology is widely welcomed for its high efficiency, high precision and low operation and maintenance costs. Especially in the processing of small workpieces, fiber laser cutting machines have shown unparalleled advantages and have become an indispensable and important equipment in the industry.

Fiber laser cutting technology uses a high-energy laser beam to cut materials, and generates high temperatures by focusing the beam, so that the cutting materials melt, evaporate or burn quickly, achieving the purpose of efficient and precise cutting.

With the popularity of personalized and customized products, the demand for processing small workpieces continues to grow, and traditional cutting methods can no longer meet the requirements of modern manufacturing. In this context, small-cutting-size fiber laser cutting machines are favored by the market for their precision, high speed and flexibility.

Product Technical Features

Small Precision Laser Cutting Machine is an advanced cutting machine widely used in manufacturing in various industries. Its efficient and precise cutting ability is favored by more and more enterprises.

1. Fully enclosed design, green glass cover window can filter the laser beam, with laser protection function, in line with European standards.

2. Adopting the famous Swiss brand Raytools laser cutting head, equipped with dynamic auto focus system, which can keep the same distance between the metal sheet and the laser head to achieve accurate cutting effect.

3. Adopts imported servo motor and precision guide rail to ensure high cutting precision, good stability and longer life.

4. With red light indication and pre-running function to ensure the fiber laser cutting machine can find the accurate cutting position.

5. With automatic oil filling function, each magnetic stripe has an oil pipe, press the oil filling switch to automatically lubricate, oil filling once every two months.

6. Specialized software can design or process graphics or text in real time. Flexible and easy to operate.

Product Details

1. Brand laser

Imported lasers are used, with stable performance, high precision, and a service life of up to 100,000 hours.

2. Auto focus laser cutting head

The focal length can be automatically adjusted according to the thickness of the material, and the cutting speed can be cut at a high speed.

3. Fast response to high-precision CNC and transmission system

It adopts marble base and gantry mobile platform structure machine tool, international famous brand linear motor or linear guide rail and precision screw drive, and bilateral servo motor synchronous drive to ensure stable transmission under high-speed cutting state and maintain excellent precision and speed. Greatly improve the long-term high-speed and stable operation of the bed.

4. Independent research and development of gas path control system

Capacitive sensors can easily realize functions such as height automatic tracking, active collision avoidance, segmented perforation, and automatic search. Fast speed, high precision, simple operation, greatly improving the quality of cutting and saving costs.

5. Integrated safety design

One-piece closed structure machine, the safety door filters the laser beam, does not hurt the eyes, prevents the debris from splashing on the human body during the cutting process, and protects the safety of the operator.

6. Professional cutting software

High-efficiency automatic typesetting function, automatic optimization of cutting path, reducing sheet waste generation. With a high-definition screen, the work is convenient and efficient.

Advantages of Small Size Laser Cutting Machine

Small cutting size fiber laser cutting machines are widely used in a variety of industries due to their specific design and technical advantages.

1. High-precision cutting

Small fiber laser cutting machines can achieve micron-level cutting accuracy and are suitable for processing fine and complex patterns. This high precision makes it occupy an important position in fields such as electronic accessories and jewelry that require extremely high craftsmanship.

2. High-speed cutting

Fiber lasers have excellent beam quality and can provide high cutting speeds. Compared with traditional cutting technology, small fiber laser cutting machines have significantly improved cutting efficiency and are suitable for mass production.

3. Takes up little space

Due to its compact structure, small fiber laser cutting machines occupy less space and are suitable for use in limited production sites. It can be flexibly arranged in various environments such as offices and workshops, saving space for enterprises.

4. Low operation and maintenance costs

Fiber laser cutting machines are relatively economical in terms of energy consumption and maintenance. Fiber laser technology generally has higher energy conversion efficiency and reduces power consumption. In addition, fiber lasers have a long life and require low maintenance, which reduces long-term operating costs.

5. User-friendly operation interface

Small fiber laser cutting machines are usually equipped with modern CNC systems and user-friendly operating interfaces, making it easy for operators to get started. The integrated software system simplifies the design and cutting process and increases work efficiency.

6. Environmental protection characteristics

Fiber laser cutting produces less waste and pollution than traditional cutting methods, and the noise generated during operation is also relatively low. Therefore, it is a more environmentally friendly manufacturing process.

7. Suitable for small batch production

In the production mode of small batches and multiple varieties, small cutting size fiber laser cutting machines can effectively meet the personalized needs of customers, allowing companies to quickly respond to market changes.

Small cutting size fiber laser cutting machines are becoming an important tool in modern manufacturing with their high precision, high efficiency, flexibility and environmental protection advantages. By improving production efficiency and product quality, it provides companies in various industries with strong competitiveness. Click here to contact Suntop Laser now for more information.

Product Specifications

Model	ST-FC6060/ST-FC1390/ST-FC2010
Table Max. cutting size	600600/1300900mm/2000*1000mm
Laser power	1000W/1500W/2000W/3000W/4000W
Cutting thickness	0.5-20mm (depend on the actual laser power)
Repeat positioning accuracy	±0.01mm/m
Maximum operating speed	40m/min
Laser type	Fiber Laser
Laser source	Raycus Brand (MAX, IPG can be choose)
Cooling mode	Water Cooling
Maximum acceleration	0.5G
Laser wavelength	1064nm
Transmission	High precision screw guide transmission
Graphic format supported	AI, PLT, DXF, BMP, DST, DWG, DXP
Working voltage	220V±10%, 50-60Hz / 380V±10%, 50-60HZ
Applicable material	All metal (stainless steel, brass, aluminum, titanium steel, etc.)
Machine weight	1300KG (depending on actual model)
Machine dimension (LWH)	165013601880mm (depending on actual model)

What Materials Can be Cut?

Mainly suitable for carbon steel, stainless steel, copper, aluminum and alloys, titanium and alloys and other metal materials.

High Precision Laser Cutting Machine samples-Suntop

What Are Laser Cutting Used For?

Laser cutting machines are widely used in many fields due to their high efficiency, precision and wide range of applications. The following are some of the main application areas:

Metal processing

Fiber laser cutting machine is widely used in metal processing industry, especially suitable for cutting all kinds of metal materials, including: stainless steel, carbon steel, aluminum alloy, copper, brass and other non-ferrous metals.

Sheet metal manufacturing

Fiber laser cutting machine is very popular in sheet metal processing, can achieve high efficiency plate cutting, suitable for manufacturing: industrial equipment shell, sheet metal chassis, structural parts and so on.

Automotive manufacturing

In the automotive industry, fiber laser cutting machines are used to cut and process various automotive parts, such as: body frames, parts brackets, bumpers and so on.

Aerospace

In order to meet the high precision and high strength material cutting needs, fiber laser cutting machine is used in the field of aerospace, suitable for: aircraft structural parts, missile and satellite parts, aviation equipment, etc.

Advertising and signage

Fiber laser cutting machines are used to make various advertising signs, signboards and display props, which can realize complex fonts and patterns cutting, and are widely used in: commercial advertisements, store signboards, exhibitions and displays.

Appliance manufacturing

In the home appliance industry, various metal casings and components are manufactured by fiber laser cutting machines, such as: refrigerator casings, washing machine panels, air conditioner casings, etc.

Construction and decoration

In the construction industry, fiber laser cutting machine can quickly cut out a variety of complex shapes of metal decorative parts, such as: iron railing, metal curtain wall, creative metal devices.

Medical equipment

In the medical equipment industry, fiber laser cutting machines are used to manufacture high-precision and complex medical equipment parts, such as: instrument housings, surgical knives, etc.

Crafts and gifts

High-precision fiber laser cutting technology is suitable for the production of exquisite handicrafts and customized gifts, such as: exquisite engraving, cutting artwork, customized souvenirs and so on.

Laser cutting machine is gradually replacing the traditional cutting technology and becoming an indispensable and important equipment in industrial production due to its high precision, good efficiency and flexibility. Click here to contact Suntop Laser today to learn more about laser cutting.

Laser Cutting Machine Video

Why Choose Suntop Laser?

There may be several reasons for choosing Suntop Laser as a brand of laser cutting machine, here are some common benefits and features that may make you consider choosing this brand:

High quality equipment

Advanced technology: Suntop Laser is committed to utilizing the latest in laser technology and innovative designs to provide efficient and accurate cutting solutions.

Durability and Reliability: Its products are often known for their high-quality materials and precision manufacturing processes, ensuring that the models are durable and stable in operation.

Wide range of application scenarios

Diversified material cutting: Suntop Laser's equipment is suitable for cutting a wide range of materials, including metal, wood, plastic, etc., to meet the needs of different industries.

A variety of models to choose from: According to the market demand, Suntop offers a variety of models and specifications, which can provide customers with diversified choices.

Superior cutting performance

High speed and accuracy: Laser cutting machines usually have high cutting efficiency and accuracy, which ensures cutting quality and maintains excellent performance even when dealing with complex shapes.

High power options: Different power options are available to enable customers to choose according to specific cutting needs such as material type and thickness.

User-friendly operation

Easy-to-use control system: Suntop's machines are usually equipped with a user-friendly interface, making operation easy and users can get started quickly.

Software compatibility: Compatibility with common design software contributes to a more efficient workflow.

Strong after-sales service

Technical Support: Provide comprehensive technical support and training to ensure that problems encountered by customers in the course of use can be resolved in a timely manner.

Maintenance and Service Guarantee: Good after-sales service and maintenance program can reduce the customer's operational risk.

Cost-effective

Reasonable price: Suntop Laser is usually competitive in price, providing good cost performance, so that customers can get a higher rate of return on investment.

Choosing a machine from Suntop Laser means that you are looking for a high-performance, highly reliable laser cutting machine that meets a wide range of cutting needs. In addition, good after-sales service and user support are key factors that set Suntop apart. Click here to contact Suntop Laser today and make sure you know exactly what you need before you buy so you can make the best choice.

FAQ

1. How can i place an order?

Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.

For further discussion, it is better to contact us with WhatsApp / WeChat / email / phone, in case of any delays.

2. What kind of display we provide?

We have laser marking machine / laser welding machine / laser cutting machine / laser cleaning / CO2 laser cutting and engraving machine / laser accessories for you choose.

3. How about the warranty?

We have 2 years warranty and lifelong maintenance.

4. What is your terms of delivery?

We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you.

5. Is the equipment difficult to maintain and service?

No, maintenance is relatively simple. It is recommended to regularly check the laser light path, cooling system and clean the optical lens to ensure the best performance of the equipment. Due to the long life of its fiber laser, the maintenance frequency is low.

6. What is the energy consumption of a small fiber laser cutting machine?

Compared with other cutting methods, the energy consumption is low. The actual energy consumption of the equipment depends on the model of the laser used and the cutting process.

7. How safe is the laser cutting machine?

It is safe to operate, but safe operating procedures must be followed. The equipment is usually equipped with laser protection devices and emergency stop buttons to ensure the safety of the operator.

8. What kind of parts are suitable for processing with a small fiber laser cutting machine?

Small fiber laser cutting machines are very suitable for processing ultra-small and delicate parts such as electronic components, jewelry, logos, artistic decorations, etc.

9. How to choose a suitable fiber laser cutting machine?

When choosing a suitable fiber laser cutting machine, the following factors should be considered:

The type and thickness of the material to be cut

The requirements for cutting accuracy and speed

The budget and comprehensive maintenance cost of the equipment

The supplier's after-sales service and technical support

10. Can the cutting design be programmed through software?

Yes, it is equipped with user-friendly numerical control (CNC) software. Users can design graphics through computer drawing software (such as AutoCAD, SolidWorks, etc.), and then import them into the cutting software for processing.

11. Is it difficult to train a small fiber laser cutting machine?

No, the operation interface is usually more intuitive, and after simple training, operators can generally quickly master the use of the equipment.
