Details Product Parameters Samples Video
1. Integrated design, reasonable structure, dustproof, good heat dissipation, effectively prolonging the service life of machine parts.
2. Equipped with 10 meters of original optical fiber cable, it can be moved and operated, and can clean the parts that are not easy to reach.
3. The lightweight design of the hand-held cleaning head makes it easy to handle and can work for a long time.
4. By adjusting the laser process parameters, the pollutants can be effectively removed without damaging the surface of the substrate, making the surface look like new again.
5. Flexible optical fiber transmission can be used to cooperate with robot integration to improve work efficiency and reduce labor costs.
1. Laser cleaning head
Light weight only 0.7KG, flexible and convenient to clean metal parts of any shape, with a wide cleaning width, up to 300mm. Equipped with a safety monitoring system.
2. Operation interface
Advanced resistive touch screen with higher sensitivity, intelligent control, supports multiple languages (English, Spanish, German, Italian, French, Russian, Turkish, etc.)
3. Laser source
We use a customized 45um core diameter cleaning fiber laser with a lifespan of 100,000 hours and maintenance-free.
4. Water chiller
Double circulating water cooling makes the laser source and cleaning head cool better, and the temperature control sensor adopts imported brands.
5. Cleaning connection fiber
The cable distance from the laser cleaning head to the machine is 10 meters, and there is no need to move the machine when laser welding the workpiece.
6. Wide range of cleaning
The maximum cleaning area is 300*300mm, and the efficiency is high.
1. Wide range of applications: Laser cleaning can remove various types of pollutants on the surface of various materials, achieving a cleanliness that cannot be achieved by conventional cleaning. Moreover, the pollutants on the surface of the material can be selectively cleaned without damaging the surface of the material.
2. Operational safety: It has multiple safety alarm functions, high safety, and guarantees the absolute safety of operators during work.
3. Good cleaning effect: no grinding and non-contact, no thermal effect, no mechanical force on the object to be cleaned, and no damage to the surface of the object to be cleaned.
4. Environmental protection: No need to use any chemicals and cleaning fluids, the waste after cleaning is basically solid powder, small in size, easy to store, recyclable, no photochemical reaction, and no pollution.
5. Low cost: The initial investment is high, but it can be used stably for a long time, with a service life of up to 10 years, low operating cost, fast speed, high efficiency, time-saving, and a quick return on investment.
Cleaning ability (only for reference)
Cleaning surface | 1000W | 1500W | 2000W |
Floating embroidery (20um) | 10m³/h | 15m³/h | 20m³/h |
Paint (120um) | 4m³/h | 6m³/h | 8m³/h |
Rusting (100um) | 2.5m³/h | 4m³/h | 5m³/h |
Application materials
Suitable for removing resin, paint, oil stains, stains, dirt, rust, coatings, etc. from the surface of objects.
Application industry
Widely used in aerospace, electronic products, automobile manufacturing, track facilities, high-end machine tools, mold industry, food processing, shipbuilding, military industry, medical treatment, cultural relics, etc.
Model | ST-FC1000H | ST-FC1500H | ST-FC2000H |
Power | 1000W | 1500W | 2000W |
Power consumption | 3000W | 4500W | 6000W |
Max. cleaning width | 170*170mm | 250*250mm | 300*300mm |
Laser wavelength | 1064nm | ||
Operation mode | Handheld | ||
Power adjustment range (%) | 10-100 (Gradient adjustable) | ||
Cleaning head weight | 0.7Kg | ||
Delivery cable length | 10M (can be customized) | ||
Input power | 220V±10% 50-60HZ | ||
Cooling system | Water Cooled with automatic pumping function | ||
Machine weight | 220KG | 230KG | 280KG |
Machine size | 935*720*1248mm | 1500*880*1160mm |
