Ezcad Rotary Marking

The EZCAD rotary laser marking system has the advantages of flexibility and portability, all-round marking, high-precision marking, high-efficiency production, adaptability to multiple materials, low maintenance costs and flexible parameter adjustment. This makes it suitable for occasions that require flexible and rapid marking, such as advertising production, decoration, handicraft production, etc.
Product Model: ST-FL20P/ST-FL30P/ST-FL50P/ST-FL100P
Laser power: 20W/30W/50W/60W
Working area:110*110mm/150*150mm/200*200mm/300*300mm/450*450mm

Availability:

Quantity:



Inquire PDF Export

Product Description

Details Product Parameters Samples Video

What Is Rotary laser marking Machine?

Laser marking technology is a non-contact processing method that uses laser beams to mark the surface of materials. It is widely used in many fields such as industrial manufacturing, medical equipment, electronic products and personalized customization. With the development of science and technology and the increasing market demand for high-precision marking, laser marking technology has gradually replaced traditional marking methods such as engraving, printing and etching with its high efficiency, durability and flexibility, and has become an important tool in modern manufacturing.

As an innovative form of laser marking technology, the rotary laser marking machine uses a rotating mechanism with laser emission to achieve efficient and fine marking of objects of various shapes and sizes. The device can not only mark flat surfaces, but also easily handle complex surfaces such as cylindrical and special-shaped surfaces, greatly expanding the application range of laser marking. The rotary laser marking machine has high speed, high precision and relatively flexible operation capabilities, which can meet different process requirements and industrial needs. Its wide applicability enables it to show excellent performance in harsh industrial environments, providing an ideal solution for enterprises.

Product Technical Features

● All-in-one integrated design, better meet the user's industrial production needs, small size, high space utilization.

● The use of high-precision brand-name wavelength F-theta lens, which can realize high-speed and high-precision laser marking, and no deformation of text and image for a long time.

● The equipment adopts air-cooling technology, without the support of water-cooling system, longer service life.

● High beam quality, small spot size, narrow marking line width, more suitable for fine marking.

● Adopting red light positioning system, easy to position and high positioning accuracy.

● The machine can be equipped with other optional accessories according to the actual product laser marking needs of customers, such as rotary device, 2D/3D worktable, pen rotary table and other fixtures.

● Suntop fiber laser marking machine factory after strict aging test, the laser beam continuous 24 hours output, to ensure 100% stability of the machine.

Product Details

Rotary laser marking Machine Laser source-Suntop

Laser source

Good beam quality, stable performance, long service life (100,000 hours), and maintenance-free. MAX, Raycus, JPT and other brands can choose.

High quality galvanometer

The high-speed digital galvanometer scanning head has good running stability and high positioning accuracy, which can realize high-speed marking and high precision.

Rotary laser marking Machine High quality galvanometer-Suntop

Rotary laser marking Machine F-theta lens-Suntop

F-theta lens

Intelligent F-theta lens, the fiber laser beam is focused to the surface of the workpiece through the lens, and the energy is sufficient.

Built-in air cooling

With built-in air cooling design, the heat dissipation performance is better, can effectively extend the service life of optical components.

Rotary laser marking Machine Built-in air cooling-Suntop

Rotary laser marking Machine Rotating device-Suntop

Rotating device

Equipped with advanced control system, it can realize automatic operation, greatly reduce manual intervention and improve production stability.

Parameters such as marking content, speed and depth can be flexibly set as needed to meet different production needs.

Red light positioning

Scanning with red light before marking, previewing the marking position in advance, identifying the positioning size, so that the marking position of each workpiece is accurate and error-free.

Rotary laser marking Machine Red light positioning-Suntop

Rotary laser marking Machine Control panel-Suntop

Control panel

BJJCZ brand original EZCAD control system has the characteristics of high stability, easy operation and good performance.

All-aluminum operating table

The all-aluminum operating table is selected, the porous position is flexibly positioned, and the processing direction is flexibly adjustable.

Rotary laser marking Machine All-aluminum operating table-Suntop

Advantages of Rotary Laser Marking

Rotary laser marking machines offer several advantages that make them popular in the manufacturing and marking world.

1. High precision:

Rotary laser marking machines can achieve very detailed markings, ensuring that every mark is clear and precise. This is especially important for industries that require precision marking, such as electronics and medical devices.

2. High efficiency:

This equipment can achieve rapid switching and continuous operation during the marking process, significantly improving production efficiency and reducing production cycle, and is suitable for mass production needs.

3. Non-contact processing:

Rotary laser marking uses a non-contact method to avoid physical damage to the material surface. This is especially important for fragile or complex-shaped products, reducing material waste and improving finished product quality.

4. Strong adaptability:

Rotary laser marking machines are capable of processing objects of various shapes and sizes, including cylindrical, square and irregularly shaped materials. Its flexibility enables it to meet diverse application needs.

5. Durability and stability:

The marking effect of laser marking is time-tested and is not easy to wear or fade, ensuring long-term durability. This is especially important for products that require long-term labeling (such as industrial equipment, etc.).

6. Environmental protection and safety:

The laser marking process does not require the use of any chemicals, reducing environmental pollution. In addition, its non-contact nature also reduces safety hazards.

7. Personalization and customization:

The rotary laser marking machine can achieve a high degree of personalized marking, which is suitable for customers to customize product identification according to their needs and meet the individual needs of the market to the greatest extent.

8. Low maintenance cost:

Compared with traditional marking equipment, the operation and maintenance costs of rotary laser marking machines are lower. The wear and failure rate of mechanical components is reduced, thereby reducing long-term use costs.

Rotary laser marking machines are widely used in many industries due to their high efficiency, accuracy and environmental protection, providing enterprises with high-quality marking solutions and promoting the modernization of industrial production. Click here to contact Suntop Laser now for more detailed information.

Optional Configuration

D80 Rotating Shaft

D57 Small Chuck

D57 Mini Chuck

Rotating Shaft

Round Turntable

2D Table (X.Y direction)

Cutting Fixture

LED Light

Product Specifications

Laser Power	20W	30W	50W	60W	70W	100W
Model	ST-FL20P	ST-FL30P	ST-FL50P	ST-FL60P	ST-FL70P	ST-FL100P
Max Marking Range	110110mm /150150mm	200*200mm	300*300mm	450*450mm	450*450mm	450*450mm
Depth of Single Marking	0.01mm	0.03mm	0.06mm	0.07mm	0.07mm	0.1mm
Same pattern marking efficiency	10s	7 s	4s	3s	3s	2s
Whole Machine Power	600W/h
Laser Type	Fiber Laser
Laser Source	MAX Brand (Raycus can choose)
Control Software	EZCAD
Cooling Mode	Air Cooling
Working Accuracy	±0.002MM
Marking Speed	0-7000mm/s
Repetition Frequency	20-100KHz
Laser Wavelength	1064nm
Minimum Font for Marking	0.15mm
Working Voltage	220V±10%, 50/60 Hz
Graphic Format Supported	AI, PLT, DXF, BMP, DST, DWG, DXP
Applicable Material	All metal (Stainless steel, Carbon steel, Brass, etc.) and some plastic (ABS, PVC, PES, ETC.)
Optional Accessories to Purchase	D80 Rotating Shaft/ D57 Small Chuck/2D Table (X.Y direction)/ Cutting Fixture
Net Weight (KG)/ Gross Weight	38KG / 48KG
Machine Dimension	420300550mm (LWH)

What Materials Can be Marked?

Suitable for working with most metal marking applications such as Gold, Silver, Stainless Steel, Brass, Aluminum, Steel, Iron Titanium etc., and can also mark on many nonmetal materials, such as ABS, Nylon, PES, PVC etc.

Rotary laser marking Machine samples1-Suntop

Rotary laser marking Machine samples2-Suntop

Rotary laser marking Machine samples3-Suntop

Rotary laser marking Machine samples4-Suntop

Rotary laser marking Machine samples5-Suntop

Rotary laser marking Machine samples6-Suntop

What Are Rotary Laser Marker Used For?

Rotary laser marking machines are used in multiple industries and fields due to their high precision, high efficiency and wide material applicability. Here are some of the main uses of rotary laser marking machines:

Industrial manufacturing

- Metal parts marking: used to mark various metal parts, such as automotive parts, mechanical components, etc., to provide permanent markings, including serial numbers, barcodes and patterns.

- Tools and molds: engrave logos, specifications and other important information on tools and molds for easy traceability and management.

Electronics industry

- Electronic components: Marking on components such as circuit boards, chips, connectors, etc. to ensure product traceability and quality management.

- Home appliances: Marking logos on home appliances such as refrigerators and washing machines to increase brand recognition.

Medical industry

- Medical devices: Marking on various medical devices (such as surgical instruments, implants) to provide necessary traceability information and instructions for use.

- Pharmaceutical packaging: Marking QR codes or batch numbers on pharmaceutical packaging to ensure traceability and legality.

Aerospace

- Aviation parts: Mark aircraft parts with compliance certification and safety information to meet strict industry standards.

- Aviation equipment: Mark aviation equipment to improve management efficiency and verification accuracy.

Consumer goods

- Trophies and souvenirs: Personalize and mark customized trophies, souvenirs, etc. to increase added value and aesthetics.

- Accessories: Mark products such as jewelry and watches to enhance brand image and recognition.

Food and beverage industry

- Packaging marking: Mark production date, shelf life and barcode on food packaging to ensure food traceability and safety.

- Brand logo: Mark brand symbols or product information on beverage bottles and cans.

Machinery industry

- Equipment identification: Mark models, specifications and QR codes on machinery and equipment to facilitate daily maintenance and management.

- Machinery parts: Mark machinery parts to improve management efficiency and information communication.

Personalized Customization

- Gifts and Personalized Products: Personalized gifts and souvenirs can be customized for individual customers, providing more unique marking services.

The application of rotary laser marking machines in different industries shows its flexibility and adaptability to meet various marking needs. Click here to contact Suntop Laser for a free laser marking test.

Laser Marking vs. Inkjet Machine

Comparison	Fiber Laser Marking Machine	Inkjet machine
Print color	Black PE marking white, White PVC mark black, and may more colors depend on products	Can inkjet one color only
Laser source	You can choose UV, Fiber, RF laser source	No
Consumable parts	No	Filter needs to replaced regularly
Consumables costs	No	Expensive (Ink and solvents)
Maintenance	Minimal (Clean lens regularly)	Heavy (Ink line must be clean frequently)
Environmental	No	Ink and solvents emit a taste that’s not good for workers
Printing effect	Beautiful, permanent, never fade, even in the water	Non-permanent, easy to erase
Summary: Laser marking machine has lower usage cost, forever marking, and environmentally friendly.

Rotary laser marking Machine Video

What is The Effect of Laser Marking?

The effect of laser marking is generally considered to be very excellent and reliable, which is specifically manifested in the following aspects:

1. High precision and clarity

- Resolution: Laser marking can achieve extremely high resolution, and the marked text, patterns, barcodes and QR codes are very clear, which can meet the needs of complex designs.

- Detail performance: Delicate patterns and small fonts can be accurately marked, suitable for high-demand applications.

2. Persistence and durability

- Wear resistance: Laser marking is usually formed by removing the surface of the material or changing the structure of the material, so it has strong wear resistance and is not easy to fade or be scratched.

- Chemical resistance: The effect of laser marking is usually resistant to chemical corrosion and is suitable for products that need to be used in harsh environments.

3. Color and effect changes

- Diversity: Laser marking can achieve different effects on different materials, such as different color changes (oxide layer changes) on metal surfaces, and gray or white appearance on some plastics.

- Surface treatment: Laser marking can also be combined with surface treatment technology to further enhance the marking effect.

4. Non-destructive and environmentally friendly

- No consumables pollution: Laser marking does not require the use of ink or other chemical materials, which is environmentally friendly and reduces waste generation.

- No direct contact: Laser marking is a non-contact process that does not damage the material, thereby ensuring the integrity of the substrate.

5. Wide range of applications

- Various materials: Laser marking can be applied to a variety of materials such as metal, plastic, glass, wood, leather, etc., with strong applicability.

- Industry application: Widely used in electronics, automobiles, pharmaceuticals, food packaging, tool manufacturing and other industries.

Laser marking has performed well in many industrial and commercial fields with its high precision, durability, environmental protection and wide applicability, and is favored by more and more companies. Through laser marking, not only can the aesthetics of the product be improved, but also the recognition and durability of the product can be enhanced. Click here to contact Suntop Laser to get various material marking tests.

Why Choose Suntop Laser?

There are several advantages and reasons to choose Suntop Laser as a supplier of laser marking machines and related equipment:

Technical Strength

Advanced laser technology: Suntop Laser is usually equipped with the latest laser technology, including fiber laser, CO2 laser and UV laser, etc., which can meet the needs of different materials and applications.

Innovative products: Continuous R&D and innovation, launching new products to adapt to market changes and customer needs.

Diversified product lines

Wide range of applications: Suntop Laser provides a variety of types of laser marking machines for different industries, such as electronics, automotive, medical, food packaging, etc.

Customized solutions: Ability to provide customized laser marking solutions according to customers' special needs.

Reliable after-sales service

Strong technical support: Suntop usually provides timely technical support and training to ensure that customers can use the equipment effectively.

Long-term guarantee: Equipment usually comes with warranty and maintenance services to reduce customers' operational risks.

High-cost performance

By optimizing production processes and cost management, Suntop Laser is able to provide competitive prices to ensure that customers get a good return on their investment.

Good industry reputation

Customer testimonials and cases: Many customers have given positive comments on Suntop Laser's service and product quality, enhancing its trust in the market.

Industry experience: Years of industry experience have enabled it to better understand customer needs and provide high-quality solutions.

International market

Global market supply: Suntop Laser's products can be sold in the international market, with export capabilities and market recognition, and can provide customers with international standard services.

Choosing Suntop Laser can provide customers with high-quality laser marking solutions. Its technical strength, user experience, after-sales service, and cost-effectiveness are all factors worth considering. If you are looking for a laser marking machine or other related equipment, Suntop Laser can be a strong choice. Click here to contact Suntop Laser for more information to ensure that it meets your specific needs.

FAQ

1. How can i place an order?

Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.

For further discussion, it is better to contact us with WhatsApp / WeChat / email / phone, in case of any delays.

2. What kind of display we provide?

We have laser marking machine / laser welding machine / laser cutting machine / laser cleaning / CO2 laser cutting and engraving machine / laser accessories for you choose.

3. How about the warranty?

We have 2 years warranty and lifelong maintenance.

4. What is your terms of delivery?

We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you.

5. How does a rotary laser marking machine work?

The device generates a high-energy-density laser beam through a laser transmitter, focuses it on the surface of the material, and instantly evaporates or ablates the material at high temperature, thereby forming the desired mark.

6. How does a rotary laser marking machine work?

Laser marking provides clear, wear-resistant and durable marking effects. The marked logo is not easy to fade or wear, and can maintain good readability during long-term use.

7. What maintenance does a rotary laser marking machine require?

Regularly check the cleanliness of the laser transmitter, lens and optical fiber to ensure stable operation of the equipment. At the same time, regularly update and calibrate the software to ensure marking accuracy.

8. Is the operating cost of a rotary laser marking machine high?

The operating cost of a rotary laser marking machine is relatively low. Although the initial investment is high, its low maintenance cost, long service life and high efficiency can bring long-term economic benefits.

9. How to choose a suitable rotary laser marking machine?

The following factors should be considered when selecting a rotary laser marking machine:

Target material and its characteristics

Marking speed and accuracy requirements

Equipment scalability and flexibility

Budget and after-sales service support

10. Is the rotary laser marking machine safe?

The rotary laser marking machine is safe under normal operation. The equipment is usually equipped with safety protection measures (such as laser protection cover, emergency stop switch, etc.). Operators should follow safety regulations and wear appropriate protective equipment.
