CO2 Laser Marking Plastic

CO2 laser marking machines are very effective in marking plastic materials. Whether it is ABS, PVC, polyethylene, polypropylene or other plastic materials, laser marking machines can mark the surface with high definition and high precision. For plastic product manufacturers, using CO2 laser marking machines for product identification, QR code marking and other tasks can not only improve the aesthetics of the product, but also increase the added value of the product.
Product Model: ST-CO2L30/ST-CO2L60/ST-CO2L70/ST-CO2L80/ST-CO2L100
Laser power: 30W/60W/70W/80W/100W
Working area: 110*110/150*150/200*200/300*300mm

Availability:

Quantity:



Inquire PDF Export

Product Description

Details Product Parameters Samples Video

Product Introduction

CO2 laser marking machine is a kind of equipment that uses CO2 gas-excited laser as processing light source, and performs laser etching or cutting on the surface of materials to achieve marking, pattern engraving, text engraving and other processing processes. It is mainly composed of laser, galvanometer scanning system, control system and workbench.

Working principle:

After the CO2 laser beam generated by the laser is focused by the optical system, the laser beam is controlled by the galvanometer scanning system to move quickly on the surface of the material, thereby achieving etching and thermal action on the surface of the material to form the required mark or engraving. The control system is responsible for controlling the power, frequency, speed and other parameters of the laser, as well as coordinating the movement path of the galvanometer to ensure processing quality and efficiency.

Because CO2 laser has a long wavelength, it can be effectively absorbed and processed by many non-metallic materials. This includes common materials such as plastics, rubber, and wood, providing flexible and diverse solutions for different industries.

CO2 laser marking machines are widely used in industrial production, especially in electronics, automobiles, plastics, food packaging and other industries. It has the advantages of fast processing speed, high precision, no pollution, no contact, strong controllability, etc. It can realize the fine processing and marking of different non-metallic materials and improve the quality and aesthetics of the products.

Product Technical Features

1. Adopt the original America brand SYNRAD or China top brand DAVI brand RF metal laser generator, long service life.

2. Using high-quality optical components, high-stability laser generator, automatic control system.

3. Red light preview, marking position is clear at a glance.

4. It has high working precision, fast speed, very stable performance, can work continuously for a long time, and can be directly applied to large-scale online processing production lines.

5. Full set imported optic lenses, low consumption, good focus performance.

6. Maintenance-free, "plug and play" design, no consumables required.

Product Details

CO2 Laser Marking Plastic Laser source-Suntop

Laser source

Adopting the famous brand DAVI RF laser, with good beam mode, stable system performance, maintenance-free, suitable for industrial processing sites with large-scale, multi-variety, high-speed, high-precision continuous production.

High quality Galvo Head

High-speed digital galvanometer scanning head, good running stability and high positioning accuracy, can realize high-speed marking and high precision.

CO2 Laser Marking Plastic High quality Galvo Head-Suntop

CO2 Laser Marking Plastic Field Lens-Suntop

Field Lens

Featuring an air-spaced design and anti-reflective coating, our compact Fθ field lens ensures an excellent throughput and durability with less than 1% distortion, suitable for a wide range of environments.

Red light positioning

Quickly and accurately determine the processing position and range of laser marking to avoid processing offset or dislocation due to errors.

CO2 Laser Marking Plastic Red light positioning-Suntop

CO2 Laser Marking Plastic Control Panel-Suntop

Control Panel

BJJCZ brand original EZCAD control system, high stability, easy to operate and good performance.

All-aluminum Worktable

Powerful function, wide applicability, high-precision aluminum cleaning table standard positioning holes to meet the positioning needs of different products.

CO2 Laser Marking Plastic All-aluminum Worktable-Suntop

Product advantages

CO2 laser marking has many advantages in plastic processing, making it a widely used processing method. Here are some advantages of CO2 laser marking on plastics:

1. High precision: CO2 laser marking can achieve very fine marking and engraving, and is suitable for plastic product processing that requires high precision, such as electronic products, medical devices, etc.

2. High-speed processing: Laser marking has a fast speed and high processing efficiency. It is suitable for mass production and improves production efficiency.

3. Non-contact processing: CO2 laser marking is a non-contact processing method that will not damage the plastic surface and maintain the quality and finish of the plastic product surface.

4. Strong controllability: Parameters such as laser power, speed and focal length can be adjusted as needed to achieve precise control of the processing process.

5. Wide range of applications: CO2 laser marking is suitable for various types of plastic materials, such as ABS, PC, PVC, PMMA, etc., with strong flexibility.

6. A variety of patterns: It can realize the processing of various complex designs, texts, and patterns to meet the needs of different customers.

7. High efficiency and energy saving: CO2 laser marking is a green and environmentally friendly processing method that does not require chemical agents, does not produce waste gas and wastewater, and is energy-saving and environmentally friendly.

CO2 laser marking has the advantages of high efficiency, high precision, no damage, and strong controllability in plastic processing, and is suitable for various types of plastic product processing needs. Whether it is the identification and engraving of small products or the cutting of large products, CO2 laser marking can provide high-quality and efficient solutions, bringing convenience and benefits to the plastic processing industry.

Product Specifications

Laser Power	30W	60W	70W	80W	100W
Model	ST-CO2L30P	ST-CO2L60P	ST-CO2L70P	ST-CO2L80P	ST-CO2L100P
Max Marking Range	200*200mm	300*300mm	300*300mm	300*300mm	300*300mm
Depth of Single Marking	≤0.3mm
Laser Type	CO2 Laser
Laser source	DAVI
Control Software	EZCAD
Cooling Mode	Air Cooling
Working Accuracy	±0.002MM
Marking Speed	1-12000mm/s
Repetition Frequency	20-100KHz
Laser Wavelength	10.64μm
Minimum Font for Marking	0.15mm
Working Voltage	220V+10%, 50/60 Hz
Graphic Format Supported	AI, PLT, DXF, BMP, DST, DWG, DXP
Applicable Material	Various non-metal materials, widely used in leather, wood, textile and other industries.
Optional Accessories to Purchase	D80 Rotating Shaft/ D57 Small Chuck/2D Table (X.Y direction)/ Cutting Fixture
Net Weight (KG)/ Gross Weight	55KG / 65KG
Machine Dimension	4507501400mm (LWH)

What Are CO2 Laser Marking Plastic Used For?

CO2 laser marking is widely used in various fields in plastic processing. Its main uses include but are not limited to the following aspects:

Identification and coding

CO2 laser marking can quickly and accurately engrave text, barcodes, QR codes and other logos on the surface of plastic products for product traceability, information marking and other purposes. It is commonly used in electronic products, automotive parts, plastic packaging and other industries.

Engraving and decoration

Laser marking can engrave and decorate patterns and images on the surface of plastic products, adding unique appearance design to the products and enhancing the added value of the products.

Cutting and slotting

CO2 laser marking machines can also be used for cutting, slotting and other processing operations on plastic materials, which can quickly and efficiently realize the cutting and processing of plastic materials.

Mobile phone shell engraving

For acrylic products such as mobile phone shells, various patterns are hollowed out and laser engraved to increase the beauty and personalization of the products.

Plastic pipe engraving

For plastic pipes, various logos, texts and manufacturer information are marked.

Medical device marking

Marking the necessary information such as production batch, expiration date, registration code, etc. on medical devices.

Plastic craft engraving

Engraving, etching and other processing are performed on plastic crafts.

CO2 laser marking is widely used in plastic processing, which can meet the processing needs of identification, decoration, cutting and other processing in different industries, and provide efficient, precise and green processing solutions for plastic products.

What Can You Marking CO2 Laser Marking Plastic?

CO2 laser marking is suitable for most plastic materials, including ABS, acrylic, PVC, HDPE, LDPE, PC, PET, PP and other common plastic products. It is also suitable for other non-metallic materials such as wood, rubber, leather, cloth, jade, crystal, plexiglass, epoxy resin, etc.

ABS plastic

ABS plastic is often used in electronic product housings, automotive parts and other products. It can be marked and decorated by CO2 laser marking.

Acrylic (plexiglass)

Acrylic is a common transparent plastic material, widely used in advertising logos, crafts, decorations and other fields. CO2 laser can achieve engraving, cutting and other processing on the acrylic surface.

PVC plastic

PVC plastic is often used in products such as pipes, cards, and packaging. CO2 laser marking can also be performed on PVC plastic for marking and lettering.

HDPE and LDPE plastics

HDPE and LDPE are common polyethylene materials used to make bottles, containers, packaging bags and other products. Laser marking can also be performed on these products.

PC plastic

PC (polycarbonate) plastic has high heat resistance and impact resistance. It is often used in electronic products, automotive lamps, glasses and other products. CO2 laser can mark and decorate its surface.

PET plastic

PET is a common transparent plastic, often used in beverage bottles, food packaging and other products. CO2 laser can be used to mark PET plastic.

PP plastic

PP (polypropylene) plastic is a common thermoplastic plastic, commonly used to make bottles, food boxes, pipes and other products. Laser marking can also be performed on PP plastic.

CO2 Laser Marking Plastic Video

How to Choose CO2 Laser Marking Plastic?

When choosing a CO2 laser marker for plastic marking, there are several factors to consider to ensure that the equipment you choose can meet your needs and expected results. Here are some tips for choosing a CO2 laser for marking plastics:

1. Material type: Different plastic materials may react differently to lasers, so you need to choose a laser marker that is suitable for the type of plastic you need to process. Make sure the laser machine has a good engraving effect on the plastic material you want to mark.

2. Marking effect: Choose a CO2 laser marker based on your needs, considering factors such as the accuracy, speed, depth and clarity of the required marking. Make sure the laser marker can achieve the marking effect you expect.

3. Functionality and performance: Consider parameters such as the power, laser wavelength, processing area size, marking speed, repeatability, etc. of the laser marker. Choose the right laser marker model based on your specific needs.

4. Software support: Check the software functions that come with the laser marker to ensure that the design and marking functions you need are supported. Software usability is also an important consideration in the selection.

5. Manufacturer reputation and after-sales service: Choose a laser marking machine manufacturer with good reputation and professional after-sales service to ensure that you can get timely technical support and after-sales service during use.

6. Budget and return on investment: Choose a suitable CO2 laser marking machine based on your budget and expected return on investment. Consider factors such as the price of the equipment, operating costs, and maintenance costs.

7. Demand and production environment: Consider your demand and production environment, and choose a laser marking machine that is suitable for the production scale and production environment to ensure that the equipment can meet your production needs.

You can refer to the above suggestions. If you have any questions or want to learn more about laser marking machines, please feel free to contact us to help you choose the most suitable equipment.

Why Choose Suntop Laser?

Suntop Laser is a professional laser equipment manufacturer, and its products have a high reputation and market share in the fields of laser marking, laser cutting, laser welding and laser cleaning. Some advantages of choosing Suntop laser equipment include:

Technical strength

Suntop Laser has a strong R&D team and technical strength, and continuously innovates R&D and launches competitive laser equipment products.

Quality assurance

Suntop laser equipment uses high-quality core components and stable laser sources to ensure product quality and stability.

Customization service

Suntop Laser provides personalized customization services, customizes laser equipment according to customer needs, and meets the needs of customers in different application scenarios.

After-sales service

Suntop laser equipment provides a professional after-sales service team to provide customers with timely technical support, training and maintenance services to ensure the normal operation of the equipment.

Cost-effectiveness

Suntop laser equipment has a good performance and price ratio, affordable price, high cost performance, and saves costs for customers.

Wide application

Suntop laser equipment is suitable for multiple industries, including electronics, automobiles, medical devices, toys, packaging and other fields, meeting the laser processing needs of different industries.

Choosing Suntop laser equipment is a reliable choice, which can provide high-quality laser equipment, professional customization services and high-quality after-sales service, helping customers solve problems in the field of laser processing and improve production efficiency and product quality. If you need laser equipment, you can consider choosing Suntop laser equipment to meet your laser processing needs.

FAQ

Q1: What are the application areas of CO2 laser marking plastics?

A1: CO2 laser marking plastics are widely used in electronic products, automotive parts, plastic packaging and other industries. It can achieve high-precision, high-efficiency marking with excellent marking quality.

Q2: What is the marking effect of CO2 laser marking plastics?

A2: CO2 laser marking plastics can achieve clear and lasting marking effects. The marking pattern can be customized according to customer needs without damaging the plastic surface.

Q3: What is the cost of CO2 laser marking plastics?

A3: The cost of CO2 laser marking plastics depends on factors such as marking area and marking depth. Generally speaking, the cost of this technology is relatively low and has the advantage of long-term use.

Q4: Does CO2 laser marking plastics require special operating skills?

A4: CO2 laser marking plastics requires professionally trained operators to operate to ensure safety and marking effect. Generally speaking, marking can be performed by mastering basic operating skills.

Q5: What should be paid attention to in the maintenance of CO2 laser marking plastics?

A5: Maintenance of CO2 laser marking plastics includes regular cleaning of the lens, checking of the optical path, etc., to ensure that the equipment is in good condition to ensure the marking effect and equipment life.

Q6: How can i place an order?

A6: Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.

For further discussion, it is better to contact us with WhatsApp / WeChat / email / phone, in case of any delays.

Q7: What kind of display we provide?

A7: We have laser marking machine / laser welding machine / laser cutting machine / laser cleaning / CO2 laser cutting and engraving machine / laser accessories for you choose.

Q8: How about the warranty?

A8: We have 2 years warranty and lifelong maintenance.

Q9: What is your terms of delivery?

A9: We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you.
