1. All the lenses used in the optical path system are imported laser lenses, which reduce the loss of laser.
2. Perfect power-off renewal engraving function, the graphics can achieve good docking when power is turned on after power-off.
3. Equipped with point-and-shoot function, which allows the laser head to move precisely to the position we need.
4. Support U disk function, which can be run offline to achieve file sharing and improve work efficiency.
5. Enclosed constant temperature cooling water system to ensure long-term stable work of the laser tube.
6. can be equipped with different power CO2 lasers as standard according to different needs, and choose double-head and multi-head cutting systems to improve production efficiency and reduce production costs.
1. Adjustable laser head
The aluminum alloy adjustable laser head is lighter than other metal laser heads, which can minimize the inertia error when the laser head moves. The outer oxide film has a beautiful appearance and is durable and not deformed for a long time.
2. CO2 laser tube
The speed of light is stable, the power is high, the cutting speed is fast, and the quality is good.
Laser tube life is 10,000 hours.
Laser power 60W/80W/100W/130W/150W/200W optional.
3. High precision linear guide
Adopt high-precision high-speed belt drive, long service life.
High speed and stability, low running resistance and low noise.
The incision is precise and the work efficiency is high.
4. Mirrors and lenses
Adopt foreign imported focusing lens and reflector, high efficiency and stability.
The focal length adjustment part makes it easy to find the center of the lens and find the correct focal length.
5. LCD control panel
Which can not only work without computer, but also connect to U disk, USB communication.
Multilingual control panel, convenience of operation control.
6. Precision water chiller
CW-5000 water chiller has a temperature display, which can prevent overheating and burning, and prevent the water circulation from being cut off.
1. One machine is multi-purpose, with the function of cutting and engraving.
2. Non-contact processing, no damage to the material itself, ensuring the highest cutting quality of non-metallic materials and improving the competitiveness of manufacturers.
3. Good cutting quality, smooth cutting surface, no burr, no need for secondary processing.
4. Not affected by the shape of the workpiece, good flexibility of laser processing, can process any graphics.
5. Intelligent nesting, avoiding wasted material, saving time and energy, and improving production efficiency.
6. High safety, equipped with induction door, when the laser is opened accidentally, it will stop automatically to protect the safety of the operator.
Materials type | 40W | 60W | 80W | 100W | 120W | 150W | 200W |
Wood | 3mm | 7mm | 10mm | 12mm | 13mm | 15mm | 18mm |
Plywood | 2mm | 6mm | 10mm | 12mm | 13mm | 15mm | 18mm |
Leather | 1mm | 3mm | 4mm | 5mm | 6mm | 7mm | 10mm |
Acrylic | 2mm | 10mm | 13mm | 15mm | 17mm | 16mm | 20mm |
PVC | 1mm | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm |
Plastic (easy to melt) | 1mm | 2mm | 3mm | 4mm | 5mm | 6mm | 8mm |
Rubber | 2mm | 3mm | 4mm | 5mm | 6mm | 7mm | 10mm |
Crystal/Jade/Stone/Marble/Medal | Only for engraving | ||||||
Clothing(fabric,wool) | 2mm | 3mm | 4mm | 5mm | 6mm | 8mm | 10mm |
Bamboo Works | 1mm | 3mm | 4mm | 5mm | 6mm | 7mm | 10mm |
Suitable for all kinds of non-metallic materials, such as plastic,acrylic, jade, crystal, rubber,leather, organic glass etc.
Widely used in craft gifts, furniture, leather clothing, advertising signs, model making, food packaging, pharmaceutical packaging, electronic components, communications, clocks, glasses, printing plate making, shell nameplates and other industries.
Model | ST-CC6040 | ST-CC9060 | ST-CC1390 |
Working area | 600*400mm | 900*600mm | 1300*900mm |
Laser power | 60W/80W/100W/130W/150W/180W/200W (optional) | ||
Laser type | Hermetic and detached Co2 laser tube | ||
Control configuration | DSP | ||
Cooling mode | Water cooling and protection system | ||
Position system | Red dot | ||
Max moving speed | 1500mm/s | ||
Laser energy control | 1-100℅ set by hand or software | ||
Locating precision | <0.01 mm | ||
Min shaping character | Character: 3*3 mm, letter: 2*2 mm | ||
Worktable | Electric up and down table, with the first layer Honeycomb table and the second Aluminum knife table (Two layers) for different kinds of materials cutting | ||
Resolution ratio | ≦4500 dpi | ||
Power supply | AC220±10℅ 50 HZ, AC110±10℅ 50 HZ | ||
System environment | Windows 7/Windows 10, 32bits or 64 bits | ||
Limit switch | Induction metal limit switches for accurate positioning of X and Y positions | ||
Motion control mode | Precision linear guide | ||
Air pressure control | There is a device to adjust the air pressure at the cutting head | ||
Package Inclusion | Software, Video user menu CD Air pump gun, Power cables, USB cables, Water tank, Water Pipe, Smoke Vent-pipe, Air Blow Pipe, exhaust fan, Tools bag | ||
Dimensions(package) | 1530*850*800mm | 1600*1140*1300mm | 2050*1480 *1280mm |
Gross weight | 150KG | 306Kg | 420KG |
