3D Laser Inner Engraving Machine for Acrylic

Share to:

3D Laser Inner Engraving Machine for Acrylic

Suntop 3D crystal internal engraving machine, independently developed and designed, adopts imported laser source and self-designed control system, fully considering the special needs of different applications. Fast engraving speed, beautiful engraving pattern, laser protection fully enclosed structure, safer operation.
Product Model: ST-LCE4.5KB/ST-LCE4KB/ST-LCE3KC/ST-LCE3KD
Laser power: 3W
Max. engraving range: 300*400*130mm/150*200*80mm

Availability:

Quantity:



Inquire PDF Export

Product Description

Details Product Parameters Samples Video

What Is 3D Laser Inner Engraving Machine?

3D laser engraving machine is a high-precision laser engraving equipment, mainly used for engraving inside transparent materials (such as acrylic, glass, etc.). Unlike traditional surface engraving, 3D laser engraving uses laser beams to cut and engrave inside the material, which can create complex three-dimensional effects and deep stereoscopic patterns. This technology is widely used in personalized gifts, industrial products, publicity and advertising, decorative arts and other fields.

Working principle

The working principle of 3D laser engraving machine can be divided into the following steps:

Design phase:

The user uses computer software (such as CAD, CorelDRAW, etc.) to make a three-dimensional graphic or model to be engraved. After the design is completed, the graphics will be converted into a format suitable for the laser engraving machine.

Material preparation:

Select a suitable material (such as acrylic or glass) and place it on the workbench of the machine.

Laser setting:

Set the engraving parameters in the machine control system, including laser power, engraving speed, focal length, etc. These parameters will affect the depth and quality of engraving.

Laser emission:

The laser generator emits a high-energy laser beam, which is focused into the material through a lens. The laser processes inside the material, using the high temperature of the laser to vaporize or melt the material to form an engraving effect.

Graphic engraving:

As the laser beam moves, the engraving inside the material gradually takes shape. The laser can engrave at different depths to create complex 3D effects.

Finishing and detail processing:

After the engraving is completed, the finished product is removed from the machine, and some additional post-processing may be required, such as cleaning or surface polishing.

Through these steps, the 3D laser internal engraving machine can accurately create rich visual effects inside transparent materials to meet the needs of various industries.

Product Technical Features

1. Suntop laser developed independently, using imported laser source and self-designed control system.

2. High-speed scanning oscillator working mode, the speed can reach 300,000 points/minute, saving engraving time.

3. Sealed and integrated design, good beam quality and high stability for long-term stable work.

4. Good engraving quality and high resolution. The engraving pattern is exquisite, crystal clear, with a strong sense of three-dimensionality.

5. Non-contact engraving process, do not damage the product, maintain the original shape and quality.

6. Small size and light weight. Simple operation, friendly software interface, no need to make plates, the content can be edited at will.

Product Details

1. 3D camera

Equipped with self-developed software and 3D camera, it can design exquisite and precise human portraits.

2. High quality slide rail

Reduce friction, long service life and reduce use cost.

3. X, Y, Z axis motor

Powerful X, Y, Z sensors protect high precision movement and engraving.

4. Water cooling system

There is an exhaust fan at the back to help with cooling. There is a water cooling system inside the machine.

5. Universal wheel

Allows horizontal 360-degree rotation, durable, strong impact resistance, easy to move.

Advantages of 3D Laser Inner Engraving Machine

3D laser engraving machines have many advantages that make them popular in a variety of applications. Here are some of the main advantages:

1. High-precision engraving

Laser technology can engrave with micron-level accuracy, ensuring that details and complex patterns can be accurately reproduced, suitable for making high-quality artworks and customized products.

2. 3D effect

Compared with traditional surface engraving, 3D laser engraving can create a three-dimensional effect of depth and layering inside the material, making the finished product more three-dimensional and visually impactful.

3. Material diversity

3D laser engraving machines are suitable for a variety of transparent materials, such as acrylic, glass, crystal, etc., which makes them widely used in different fields, such as crafts, souvenirs, etc.

4. Personalized customization

The device supports personalized design, and users can customize it according to different needs, which is especially popular in the production of gifts, trophies and medals.

5. Contactless processing

Laser engraving is contactless and will not cause mechanical damage to the surface of the material, reducing the generation of waste in the production process.

6. Fast processing speed

The relatively high engraving speed improves production efficiency and can complete complex engraving tasks in a shorter time.

7. Environmental protection and safety

The laser engraving process does not produce hazardous waste, and most equipment is equipped with a fume exhaust system, which can effectively control smoke and odor and improve the safety of the working environment.

8. Low maintenance cost

The maintenance of the laser engraving machine is relatively simple and low-cost, reducing the equipment maintenance burden of the enterprise.

9. Programmable and automated

Through computer programming, 3D laser engraving machines can achieve a high degree of automation, reduce manual intervention, and improve production efficiency and consistency.

10. Repeatability

The laser engraving has high consistency and can easily repeat the same design, which is suitable for mass production and series products.

These advantages make 3D laser engraving machines more and more widely used in crafts manufacturing, industrial design, advertising production and personalized gifts. Click here to contact Suntop Laser now for more information.

Product Specifications

Model	ST-LCE4.5KB	ST-LCE4KB	ST-LCE3KC	ST-LCE3KD
Laser frequency	4500HZ	4000HZ	3000HZ	3000HZ
Max. engraving speed	280000 dots/min	240000 dots/min	180000 dots/min
Max. engraving range	300400130mm			15020080mm
Laser pumping	Semiconductor diode
Laser wavelength	532nm
Max. pulse energy	1.2MJ
Laser power	3W
Q-Mode	Acousto-optic-Q
Pulse width	7ns
Beam quality	M2＜1.5
Laser head quantity	One
Resolution	800-1200DPI
Focal length	≥100mm
Focus point diameter	0.02mm
Cooling mode	Air cooling
Application materials	Crystal, transparent glass, acrylic and plastics etc.
Input power	AC220V±10% 50-60HZ

Which Materials Can be Engraved?

Suitable for crystal cube, transparent glass/acrylic and plastic etc.

3D Laser Inner Engraving Machine for Acrylic samples1-Suntop

3D Laser Inner Engraving Machine for Acrylic samples2-Suntop

3D Laser Inner Engraving Machine for Acrylic samples3-Suntop

3D Laser Inner Engraving Machine for Acrylic samples4-Suntop

3D Laser Inner Engraving Machine for Acrylic samples5-Suntop

3D Laser Inner Engraving Machine for Acrylic samples6-Suntop

3D Laser Inner Engraving Machine for Acrylic samples7-Suntop

3D Laser Inner Engraving Machine for Acrylic samples8-Suntop

3D Laser Inner Engraving Machine for Acrylic samples9-Suntop

3D Laser Inner Engraving Machine for Acrylic samples10-Suntop

3D Laser Inner Engraving Machine for Acrylic samples11-Suntop

3D Laser Inner Engraving Machine for Acrylic samples12-Suntop

What Are the 3D Laser Inner Engraving Used For?

3D crystal laser engraving machines are widely used in many industries due to their high precision and powerful functions.

Gift industry

Personalized gifts: Users can customize crystal trophies, souvenirs, birthday gifts, etc., which become a unique way of expression for individuals or companies.

Wedding souvenirs: Such as customized crystal wedding photo frames, love theme engravings, etc., become precious memories for the newlyweds and their families.

Crafts industry

Artworks: The engraved products have unique artistic value and can be used as works for exhibitions or solo exhibitions.

Decorations: Such as crystal balls, landscape carvings and animal shapes, etc., are widely used for decoration in homes or commercial places.

Advertising and marketing

Promotional products: Companies can use customized crystal trophies, key chains, etc. as promotional gifts to increase brand exposure and customer interaction.

Office decoration: Customized crystal ornaments with company logos or mottos can be used for corporate image promotion.

Education industry

Scholarships and honorary awards: Schools and institutions can use customized crystal trophies to commend outstanding students or teams.

Scientific displays: Used to display three-dimensional scientific models or educational materials.

Souvenir industry

Monuments or memorials: Use crystal laser engraving machines to make personalized memorials to commemorate important events or people.

Pet memorials: You can engrave portraits of pets as spiritual sustenance.

Wedding industry

Customized crystal photo frames: Used to display wedding photos or anniversaries, becoming precious memorials for couples.

Crystal wedding cakes: Make exquisite crystal decorations for the top of wedding cakes.

Medical and scientific fields

Medical models: Can be used to make three-dimensional models of diseases, organs, etc., to facilitate medical education and research.

Scientific research display: Such as displaying scientific research results such as molecular structure to enhance visual effects.

Architecture and interior design

Model display: Make crystal displays of architectural models or interior design concepts for construction companies and designers to enhance the visual appeal of the project.

Technology and electronic products

Product promotion: Use crystal trophies and souvenirs as gifts to attract consumers when new products are released.

External decoration of smart products: Add exquisite engravings to the outside of smart devices to enhance the beauty of the product.

The above are the wide applications of 3D crystal laser engraving machines in various industries. This innovative technology not only improves production efficiency, but also meets personalized market needs. Click here to contact Suntop Laser immediately to learn more.

3D Laser Inner Engraving Machine Video

How to Choose 3D Laser Inner Engraving Machine?

Choosing the right 3D laser engraving machine requires considering several factors to ensure that the equipment meets your specific needs and budget.

1. Application requirements

Target products: First, clarify the type of product you plan to engrave (such as crystal, glass, acrylic, etc.). Different materials may require different types of lasers and process configurations.

Engraving accuracy: Different industries have different requirements for engraving accuracy. Make sure the selected equipment meets the accuracy standards you need.

2. Laser type

Laser engraving machines usually use different types of lasers, mainly CO2 lasers and fiber lasers. CO2 lasers are suitable for engraving non-metallic materials, while fiber lasers are more suitable for metal materials. Material properties should be considered when choosing.

3. Working area

Engraving size: Choose the appropriate working area according to the size of the product to be engraved. Make sure the selected model has enough engraving space.

4. Machine power

Laser power directly affects engraving speed and depth. Generally, higher-power devices can complete deep engraving faster, but it is necessary to balance power consumption with the required accuracy.

5. Control system

Check whether the model is equipped with a user-friendly control interface, supports multiple file formats (such as DXF, AI, BMP, etc.), and the ease of use and functions of the software (such as design editing).

6. Speed and efficiency

Understand the working speed and production efficiency of the model to determine whether it can meet your production needs, especially when producing in large quantities.

7. Equipment quality and brand

Choosing a well-known brand and manufacturer can usually ensure the stability and durability of the equipment. Reading user reviews and case studies can provide additional information.

Check its after-sales service, warranty period, and access to consumable parts.

8. Cost and budget

Clearly define the budget range, including equipment purchase costs, maintenance costs, and consumables. Evaluate the cost-effectiveness to ensure the best return on investment.

9. Safety and certification

Verify whether the equipment meets local safety standards and certification requirements to ensure operational safety, especially when used in a production environment.

10. Technical support and training

Ensure that the manufacturer provides good technical support and can provide operation training when necessary to reduce the learning curve during equipment operation.

11. Maintenance and care

Understanding the maintenance frequency and difficulty of the equipment, regular maintenance and care are essential to maintaining the performance of the equipment.

By comprehensively considering the above factors, you can better choose the 3D laser engraving machine that suits your needs to ensure its efficient and stable performance in production. Click here to consult Suntop Laser immediately to recommend a suitable laser engraving machine for you.

Why Choose Suntop Laser?

There may be multiple reasons to choose Suntop Laser. Here are some common advantages and features to help you understand why many companies may prefer Suntop Laser's equipment:

Professional manufacturer

As a professional manufacturer of laser equipment, Suntop Laser usually has rich experience and a certain market reputation in the field of laser technology.

High-quality products

Suntop Laser focuses on product quality and uses high-standard materials and components to ensure the durability and reliability of the equipment.

Technological innovation

Many laser equipment manufacturers are committed to technological innovation. Suntop Laser may have competitive advantages in laser beam quality, speed and accuracy.

Diversified product line

Suntop Laser may provide a variety of models and specifications of laser engraving machines to meet the needs of different users, including the needs of different materials and application scenarios.

Good user reviews

Customer word of mouth and user cases usually reflect the actual performance and reliability of the equipment. Choosing a brand with good user feedback can reduce risks.

Complete after-sales service

Suntop Laser may provide comprehensive after-sales support, including technical support, maintenance services and training, to ensure that problems encountered by users during use can be solved in a timely manner.

Reasonable price

With a competitive pricing strategy, Suntop Laser can provide enterprises with cost-effective equipment to help users achieve the best performance within their budget.

Customization plan

Suntop Laser may provide customized equipment services to meet specific customer needs and increase flexibility and adaptability.

Easy operation

If its equipment has a user-friendly operating interface and software, it can lower the technical threshold and make it easier for operators to get started.

These advantages make Suntop Laser a preferred brand for many companies. Of course, when making the final decision, it is recommended that you combine your own needs, budget and market research to ensure that you choose the most suitable product.

FAQ

1. What is a 3D laser engraving machine?

A 3D laser engraving machine is a device that uses laser technology for internal engraving. It can perform high-precision engraving and marking inside a variety of transparent materials (such as acrylic, glass, etc.). Compared with traditional engraving technology, laser engraving can achieve more complex and finer patterns.

2. Is the 3D laser engraving machine difficult to operate?

It is equipped with user-friendly control software and is relatively simple to operate. Operators may need basic training to become familiar with the use, maintenance and software operation of the machine.

3. What are the maintenance requirements of a 3D laser engraving machine?

Regular maintenance includes:

Cleaning laser optical components (such as lenses and lenses)

Checking and replacing protective covers

Regularly checking whether the cooling system is normal

Ensuring that the device's software is updated

4. What is the engraving speed of 3D laser engraving?

Generally speaking, laser engraving machines have a high engraving speed, but the specific engraving speed varies depending on factors such as materials, engraving complexity and device model

5. What is the price range of 3D laser engraving machines?

The price of 3D laser engraving machines varies depending on the brand, model, function and specifications, and the price usually ranges from a few thousand dollars to tens of thousands or even higher. It is recommended to compare and choose according to your needs and budget.
