30w CO2 Laser Marking Machine

CO2 laser marking machine is a device that uses CO2 laser technology to mark, engrave and cut, and is widely used in the processing of non-metallic materials (such as wood, plastic, leather, paper, etc.). It has the advantages of high efficiency, precision, non-contact, and no consumables, and can achieve high-quality product identification and personalized customization. It is widely used in consumer products, industrial identification, artwork production and packaging and other fields.
Product Model: ST-CO2L30/ST-CO2L60/ST-CO2L70/ST-CO2L80/ST-CO2L100
Laser power: 30W/60W/70W/80W/100W
Working area: 110*110/150*150/200*200/300*300mm

Availability:

Quantity:



Inquire PDF Export

Product Description

Details Product Parameters Samples Video

Product Introduction

In today's highly automated and information-based manufacturing environment, the accuracy and efficiency of marking and engraving technology have become particularly important. As an advanced marking technology, CO2 laser marking machine has gradually become an indispensable tool in various industries with its high efficiency, precision and environmental protection.

1. Definition of CO2 laser marking machine

CO2 laser marking machine is a device that uses a laser beam generated by a carbon dioxide laser to process the surface of a material. Its basic principle is to generate high temperature on the surface of the material by focusing the laser beam, causing the material to evaporate, melt or chemically react, thereby completing the marking or engraving process. CO2 laser marking machines are usually used for non-metallic materials, but can also be used to mark certain metal surfaces.

1. Technical background and development history

Laser technology was first developed in the 1960s and was initially used in the medical and military fields. With the growing demand for industrial manufacturing, laser technology has gradually expanded to the field of material processing. In particular, the emergence of CO2 laser marking machines has made the marking of non-metallic materials more efficient and accurate. With the advancement of laser technology, CO2 laser marking machines have continued to improve in terms of power, control accuracy and ease of operation, and are widely used in packaging, electronics, automobiles and consumer products.

Product Technical Features

● It uses imported RF CO2 laser. The unique integrated maintenance-free sealing design ensures more reliable operation of the laser.

● It uses a switching power supply DC power supply, without dangerous high voltage electricity.

● It can work continuously for more than 24 hours and is a durable and highly reliable industrial laser source.

● The desktop design is small in size and can be easily installed on a workbench or a small processing machine. It has stronger processing capabilities than traditional gas flow lasers.

● Red light preview, the marking position is clear at a glance.

● The equipment uses air cooling technology, does not require water cooling system support, and has a longer service life.

● Suntop Fiber Laser Marking Machine is subjected to strict ageing tests and continuous 24-hour laser beam output before leaving our factory to ensure 100% machine stability.

Product Details

CO2 Laser Marking Plastic Laser source-Suntop

Laser source

Adopting the famous brand DAVI RF laser, with good beam mode, stable system performance, maintenance-free, suitable for industrial processing sites with large-scale, multi-variety, high-speed, high-precision continuous production.

High quality Galvo Head

High-speed digital galvanometer scanning head, good running stability and high positioning accuracy, can realize high-speed marking and high precision.

CO2 Laser Marking Plastic High quality Galvo Head-Suntop

CO2 Laser Marking Plastic Field Lens-Suntop

Field Lens

Featuring an air-spaced design and anti-reflective coating, our compact Fθ field lens ensures an excellent throughput and durability with less than 1% distortion, suitable for a wide range of environments.

Red light positioning

Quickly and accurately determine the processing position and range of laser marking to avoid processing offset or dislocation due to errors.

CO2 Laser Marking Plastic Red light positioning-Suntop

CO2 Laser Marking Plastic Control Panel-Suntop

Control Panel

BJJCZ brand original EZCAD control system, high stability, easy to operate and good performance.

All-aluminum Worktable

Powerful function, wide applicability, high-precision aluminum cleaning table standard positioning holes to meet the positioning needs of different products.

CO2 Laser Marking Plastic All-aluminum Worktable-Suntop

Advantages CO2 laser marking

CO2 laser marking machines have many advantages that make them a popular device in various material processing fields.

1. High precision

CO2 laser marking machines can achieve extremely high marking accuracy and can clearly engrave complex patterns, text and barcodes to meet high quality standards. Its high-resolution laser beam ensures perfect presentation of details.

2. Fast processing

This model has the ability to mark quickly, especially suitable for mass production. This efficient processing method greatly improves production efficiency and reduces production costs.

3. Non-contact processing

The CO2 laser marking process is non-contact and does not exert mechanical pressure on the material, thereby reducing the risk of material damage. This is especially suitable for processing brittle or fragile materials such as glass and plastic.

4. Environmental protection and safety

Compared with traditional engraving and printing methods, CO2 laser marking machines do not require the use of ink or chemical reagents, which reduces pollution emissions and reduces the impact on the environment. At the same time, laser marking is a process without physical contact, which improves work safety.

5. Low maintenance cost

The mechanical structure of CO2 laser marking machine is relatively simple, and the long laser tube saves maintenance time and cost. The durability and long-term reliability of the equipment also save enterprises the cost of frequent maintenance and replacement of equipment.

6. Programmable and flexible

The equipment is usually equipped with advanced software, which allows users to easily design and modify the marking content. This flexibility makes personalized customization easier and can quickly respond to market needs.

7. Cost-effectiveness

Although the initial investment is high, due to its efficient production capacity and low maintenance costs, it can effectively reduce the production cost of enterprises and improve the return on investment in the long run.

8. Good marking effect

The effect of laser marking is long-lasting and will not fade or damage due to time or environmental changes. It is suitable for long-term identification and traceability needs.

With its multiple advantages, CO2 laser marking machine has become an important tool for processing and identification in many industries, promoting the improvement of production efficiency and product quality. Click here for more information

Product Specifications

Laser Power	30W	60W	70W	80W	100W
Model	ST-CO2L30P	ST-CO2L60P	ST-CO2L70P	ST-CO2L80P	ST-CO2L100P
Max Marking Range	200*200mm	300*300mm	300*300mm	300*300mm	300*300mm
Depth of Single Marking	≤0.3mm
Laser Type	CO2 Laser
Laser source	DAVI
Control Software	EZCAD
Cooling Mode	Air Cooling
Working Accuracy	±0.002MM
Marking Speed	1-12000mm/s
Repetition Frequency	20-100KHz
Laser Wavelength	10.64μm
Minimum Font for Marking	0.15mm
Working Voltage	220V+10%, 50/60 Hz
Graphic Format Supported	AI, PLT, DXF, BMP, DST, DWG, DXP
Applicable Material	Various non-metal materials, widely used in leather, wood, textile and other industries.
Optional Accessories to Purchase	D80 Rotating Shaft/ D57 Small Chuck/2D Table (X.Y direction)/ Cutting Fixture
Net Weight (KG)/ Gross Weight	55KG / 65KG
Machine Dimension	4507501400mm (LWH)

What Materials Can be Marked?

Suitable for all kinds of non-metallic materials, such as wood, plastic, acrylic, rubber, leather, cloth, jade, crystal, plexiglass, epoxy resin, etc.

CO2 Flying Laser Marking Machine Sample1-Suntop

CO2 Flying Laser Marking Machine Sample2-Suntop

CO2 Flying Laser Marking Machine Sample5-Suntop

CO2 Flying Laser Marking Machine Sample6-Suntop

CO2 Flying Laser Marking Machine Sample11-Suntop

CO2 Flying Laser Marking Machine Sample12-Suntop

CO2 Flying Laser Marking Machine Sample7-Suntop

CO2 Flying Laser Marking Machine Sample4-Suntop

CO2 Flying Laser Marking Machine Sample9-Suntop

What is Laser Marking Used For?

Widely used in craft gifts, furniture, leather clothing, advertising signs, model making, food packaging, pharmaceutical packaging, electronic components, communications, clocks, glasses, printing plate making, shell nameplates and other industries.

CO2 Flying Laser Marking Machine Application1-Suntop

CO2 Flying Laser Marking Machine Application9-Suntop

CO2 Flying Laser Marking Machine Application7-Suntop

CO2 Flying Laser Marking Machine Application2-Suntop

CO2 Flying Laser Marking Machine Application4-Suntop

CO2 Flying Laser Marking Machine Application5-Suntop

CO2 Flying Laser Marking Machine Application3-Suntop

Laser Marking Video

Why Choose Suntop Laser?

Suntop Laser is a professional laser equipment manufacturer, and its products have a high reputation and market share in the fields of laser marking, laser cutting, laser welding and laser cleaning. Some advantages of choosing Suntop laser equipment include:

Technical strength

Suntop Laser has a strong R&D team and technical strength, and continuously innovates R&D and launches competitive laser equipment products.

Quality assurance

Suntop laser equipment uses high-quality core components and stable laser sources to ensure product quality and stability.

Customization service

Suntop Laser provides personalized customization services, customizes laser equipment according to customer needs, and meets the needs of customers in different application scenarios.

After-sales service

Suntop laser equipment provides a professional after-sales service team to provide customers with timely technical support, training and maintenance services to ensure the normal operation of the equipment.

Precision Laser Engraving High cost performance-Suntop

Cost-effectiveness

Suntop laser equipment has a good performance and price ratio, affordable price, high cost performance, and saves costs for customers.

Precision Laser Engraving Comprehensive application areas-Suntop

Wide application

Suntop laser equipment is suitable for multiple industries, including electronics, automobiles, medical devices, toys, packaging and other fields, meeting the laser processing needs of different industries.

Choosing Suntop laser equipment is a reliable choice, which can provide high-quality laser equipment, professional customization services and high-quality after-sales service, helping customers solve problems in the field of laser processing and improve production efficiency and product quality. If you need laser equipment, you can consider choosing Suntop laser equipment to meet your laser processing needs.

FAQ

1. How can i place an order?

Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.

For further discussion, it is better to contact us with WhatsApp / WeChat / email / phone, in case of any delays.

2. What kind of display we provide?

We have laser marking machine / laser welding machine / laser cutting machine / laser cleaning / CO2 laser cutting and engraving machine / laser accessories for you choose.

3. How about the warranty?

We have 2 years warranty and lifelong maintenance.

4. What is your terms of delivery?

We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you.

5. What is the marking process of a CO2 laser marking machine?

The CO2 laser marking machine emits a high-energy laser beam and focuses it onto the surface of the material. After focusing, the laser generates high temperature, quickly evaporates or ablates the material, and forms the desired pattern or text. The whole process is non-contact and will not cause mechanical damage to the substrate.

6. What are the main application areas of CO2 laser marking machines?

CO2 laser marking machines are widely used in many industries, including:

Packaging industry (such as food and pharmaceutical packaging)

Electronics industry (such as circuit board marking)

Automotive industry (such as component marking)

Crafts and gifts industry

Medical industry (such as instrument and equipment marking)

7. How to maintain a CO2 laser marking machine?

Regular maintenance can extend the service life of a CO2 laser marking machine. Maintenance recommendations include:

Regularly clean the laser lens and mirror

Check and clean the cooling system and fan

Regularly check the laser tube, optical path and circuit connection

Perform maintenance according to the guidelines provided by the manufacturer

8. How long can the marking effect of a CO2 laser marking machine last?

CO2 laser marking is usually very durable and not easy to fade or wear, especially in a relatively stable environment (such as dry and out of direct sunlight). However, special environments (such as high temperature, high humidity, etc.) may affect the durability of the mark.

9. How to choose a suitable CO2 laser marking machine?

When choosing a CO2 laser marking machine, you can consider the following factors:

Marking speed and accuracy requirements

The type of material processed and its thickness

Budget and return on investment

The required laser power and beam quality

Ease of operation and ease of use of software

10. What is the operating cost of the laser marking machine?

The daily operating cost of a CO2 laser marking machine is usually low. The main costs include power consumption, consumables (such as laser tubes), equipment maintenance, and labor costs. Due to its high efficiency and low maintenance characteristics, the overall operating expenses are relatively low.

11. How to solve the problem of unclear marking?

There may be several reasons for unclear marking:

Insufficient laser power or improper settings

Uneven or contaminated material surface

Inaccurate focus

Too fast machine movement

It is recommended to check the above factors, adjust machine parameters or clean the material surface.

12. Is the marking software easy to use?

Most CO2 laser marking machines are equipped with user-friendly software, which usually supports various graphic file formats (such as DXF, JPG, BMP, etc.). Users can design, edit and mark according to their needs, but new users may need to spend some time to familiarize themselves with the software interface.

13. How long is the laser tube life of a CO2 laser marking machine?

The laser tube life of a CO2 laser marking machine is generally between 2,000 and 10,000 hours, and the specific life varies depending on the frequency of use and maintenance status. It is usually necessary to check the status of the laser tube regularly according to the use of the equipment.
